SCALANCE MUM856-1 (EU), 5G-Router, Ethernet<lt/>-<gt/>3/4/5G, VPN, firewall
SKU: 6GK5856-2EA00-3DA1
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The product type designation is MUM856-1 (EU).
The SCALANCE MUM856-1 (EU) 5G router is designed for wireless IP communication of Ethernet-based applications over public 3/4/5G mobile radio networks and private 5G networks in Europe.
It includes VPN, firewall, NAT, IPv6, 4 N-Connect connections, 1 micro SIM slot, 1x10/100/1000 Mbps M12 socket, redundant DC 24 V, M12 L-encoded, PoE, -30… +70 °C, CLP slot, 1x DI and 1x DO, A-encoded, and national approvals.
Transfer rate:
Transfer rate / for Industrial Ethernet: 10 Mbit/s, 100 Mbit/s, 1000 Mbit/s.
Transfer rate:
With UMTS transmission / with downlink / maximum: 42 Mbit/s.
With UMTS transmission / with uplink / maximum: 5.76 Mbit/s.
For LTE transmission / with downlink / maximum: 1000 Mbit/s.
For LTE transmission / with uplink / maximum: 200 Mbit/s.
For 5G transmission / with downlink / maximum: 1000 Mbit/s.
For 5G transmission / with uplink / maximum: 500 Mbit/s.
Interfaces:
Number of electrical/optical connections / for network components or terminal equipment / maximum: 1.
Number of electrical/optical connections / for gigabit Ethernet / maximum: 1.
Number of electrical connections:
For network components or terminal equipment: 1.
Number of electrical connections:
For external antenna(s): 4.
For power supply: 1.
For redundant voltage supply: 1.
Type of electrical connection:
For network components or terminal equipment: M12 (8-pin, X-coded), PoE.
For external antenna(s): N-Connect (socket).
For redundant voltage supply: M12 (4-pin, L-coded).
Buy currently uses Select Automation shop pricing and checkout.
Memory:
Number of slots / for Micro-SIM card: 1.
Design of the removable storage / CLP: Yes.
Signal inputs/outputs:
Number of digital inputs: 1.
Number of digital outputs: 1.
Type of electrical connection / at the digital inputs/outputs: M12 (4-pin, A-coded).
Input voltage / at digital input / at DC: -30 ... +30 V.
Output voltage / at digital output / at DC / maximum: 24 V; 0,5 A.
Operational current / of the signalling contacts / at DC / at 30 V / maximum: 0.008 A.
Supply voltage, current consumption, power loss:
Supply voltage / from Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af: 48 V.
Consumed current:
At DC / at 24 V: 0.55 A.
At DC / at 24 V / sleep mode / maximum: 0.013 A.
With Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical: 0.27 A.
Power loss [W]:
At DC / at 24 V / typical: 13.2 W.
With Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af / typical: 12.96 W.
Supply voltage / 1 / rated value: 24 V.
Type of voltage: redundant 24 V DC power supply, M12, L-coded.
Type of voltage / 1 / of the supply voltage: DC.
Supply voltage / 2 / rated value: 24 V.
Type of voltage / 2 / of the supply voltage: DC.
Supply voltage / 3 / rated value: 48 V.
Type of voltage / 3 / of the supply voltage: DC, PoE.
Ambient conditions:
Ambient temperature:
During operation: -30 ... +60 °C.
During storage: -40 ... +85 °C.
Relative humidity / at 25 °C / during operation / maximum: 95 %.
Protection class IP: IP65.
Design, dimensions and weights:
Depth: 45 mm.
Height: 179 mm.
Width: 166 mm.
Net weight: 1300 g.
Fastening method: Wall mounting, mounting on a DIN rail with a separate mounting adapter.
35 mm top hat DIN rail mounting: Yes.
Wall mounting: Yes.
