Siemens S7-1200 Ethernet/Telecontrol CP 1243-1 Security
SKU: 6GK7243-1BX30-0XE0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Communications processor CP 1243-1 for connection of SIMATIC S7-1200:
Supply voltage, current consumption, power loss.
Type of voltage / of the supply voltage: DC
Supply voltage / 1 / from backplane bus: 5 V
Consumed current:
From backplane bus / at DC / at 5 V / typical: 0.25 A
Power loss [W]: 1.25 W
Buy currently uses Select Automation shop pricing and checkout.
Transfer rate:
At the 1st interface: 10 ...100 Mbit/s
Interfaces:
Number of interfaces / according to Industrial Ethernet: 1
Number of electrical connections at the 1st interface / according to Industrial Ethernet: 1
For power supply: 0
Type of electrical connection at the 1st interface / according to Industrial Ethernet: RJ45 port
Ambient temperature:
For vertical installation / during operation: -20 ... +60 °C
For horizontally arranged busbars / during operation: -20 ... +70 °C
During storage: -40 ... +70 °C
During transport: -40 ... +70 °C
Relative humidity at 25 °C / without condensation / during operation / maximum: 95 %
Protection class IP: IP20
Design, dimensions and weights:
Module format: Compact module S7-1200 single width
Width: 30 mm
Height: 110 mm
Depth: 75 mm
Net weight: 0.122 kg
Fastening method:
35 mm top hat DIN rail mounting: Yes
