Siemens S7-1200 Mobile Wireless CP 1243-7 LTE
SKU: 6GK7243-7KX30-0XE0 (EU)
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
Type of voltage / of the supply voltage: DC.
Supply voltage / external: 24 V.
Supply voltage / external / at DC / rated value: 24 V.
Relative positive tolerance / at DC / at 24 V: 20 %.
Relative negative tolerance / at DC / at 24 V: 20 %.
Consumed current from external supply voltage / at DC / at 24 V / typical: 0.1 A.
From external supply voltage / at DC / at 24 V / maximum: 0.22 A.
Buy currently uses Select Automation shop pricing and checkout.
Transfer rate For LTE transmission:
With downlink / maximum: 42 Mbit/s.
With uplink / maximum: 5.76 Mbit/s Ambient temperature:
For vertical installation / during operation: -20 ... +60 °C.
For horizontally arranged busbars / during operation: -20 ... +70 °C.
During storage: -40 ... +70 °C.
During transport: -40 ... +70 °C.
Relative humidity at 25 °C / without condensation / during operation / maximum: 95 %.
Protection class IP: IP20.
Design, dimensions and weights:
Module format: Compact module S7-1200 single width.
Width: 30 mm.
Height: 100 mm.
Depth: 75 mm.
Net weight: 0.133 kg.
Fastening method:
35 mm top hat DIN rail mounting: Yes.
S7-300 rail mounting: No.
Wall mounting: Yes.
