Siemens S7-1200 Mobile Wireless CP 1243-7 LTE US
SKU: 6GK7243-7SX30-0XE0 (US)
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
Type of voltage / of the supply voltage: DC.
Supply voltage / external: 24 V.
Supply voltage / external / at DC / rated value: 24 V.
Relative positive tolerance / at DC / at 24 V: 20 %.
Relative negative tolerance / at DC / at 24 V: 20 %.
Consumed current:
From external supply voltage / at DC / at 24 V / typical: 0.1 A.
From external supply voltage / at DC / at 24 V / maximum: 0.22 A.
Buy currently uses Select Automation shop pricing and checkout.
Transfer rate for LTE transmission:
With downlink / maximum: 42 Mbit/s
With uplink / maximum: 5.76 Mbit/s
Ambient temperature:
For vertical installation / during operation: -20 ... +60 °C
For horizontally arranged busbars / during operation: -20 ... +70 °C
During storage: -40 ... +70 °C
During transport: -40 ... +70 °C
Relative humidity at 25 °C / without condensation / during operation / maximum: 95 %
Protection class IP: IP20
Design, dimensions and weights:
Module format: Compact module S7-1200 single width
Width: 30 mm
Height: 100 mm
Depth: 75 mm
Net weight: 0.133 kg
