SIMATIC RF200 Reader RF250R with RS422 interface (3964R)
SKU: 6GT2821-5AC10
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC RF200 Reader RF250R with RS422 interface (3964R) without antenna IP65, -25 to +70 °C, 50 x 50 x 30 mm, compatible with ANT 1, 3, 3NO, 8, 12, 18, and 30.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Suitability for operation: ISO 15693 Transponder (MDS Dxxx), for connecting to communication modules.
Transmission frequency / rated value: 13.56 MHz
Range / maximum: 60 mm; Range is dependent on transponder type: observe.
Number of external antennas: 1.
Standard for interfaces / for communication: RS422.
Type of electrical connection:
For external antenna(s): M8, 4-pin.
For communications interface: M12, 8-pin.
Material: PA6.6.
Colour: anthracite.
Supply voltage / at DC, rated value: 24 V.
Consumed current / at DC at 24 V / typical: 0.05 A.
Ambient temperature:
During operation: -20 ... +70 °C.
During storage: -25 ... +80 °C.
During transport: -25 ... +80 °C.
Protection class IP: IP65.
Width: 50 mm.
Height: 30 mm.
Depth: 50 mm.
Fastening method: 2 x M5 screws.
Wire length for RS 422 interface / maximum: 1000 m.
