SIMATIC RF200 reader RF260R IO-Link interface V1.1
SKU: 6GT2821-6BC32
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Product designation: RF240R reader IO-Link.
SIMATIC RF200 reader RF260R IO-Link interface V1.1, IP67, -25 to +70 °C, 75x75x40 mm, with integrated antenna, 32 Byte IO, 230 Kbit/s.
Suitability for operation: ISO 15693 Transponder (MDS Dxxx), for connecting to communication modules.
Radio frequencies:
operating frequency / rated value: 13.56 MHz.
range / maximum: 135 mm; Range is dependent on transponder type.
protocol / with radio transmission: ISO 15693, ISO 18000-3.
transfer rate / with radio transmission / maximum: 26.5 kbit/s.
product feature / multitag-capable: No.
Buy currently uses Select Automation shop pricing and checkout.
electrical data:
transfer rate / at the point-to-point connection / serial / maximum: 230 kbit/s.
transmission time / for user data:
for write access / per byte / typical: 3.3 ms.
for read access / per byte / typical: 2.4 ms.
data volume / of the address range of the inputs / total: 32 byte.
data volume / of the address range of the outputs / total: 32 byte.
interfaces:
standard for interfaces / for communication: IO-Link V1.1.
type of electrical connection: M12, 4-pin.
mechanical data:
material: PA6.6.
colour: anthracite.
tightening torque / of the screw for securing the equipment / maximum: 1.5 N·m.
mounting distance / relating to metal surfaces / recommended / minimum: 0 mm.
supply voltage, current consumption, power loss:
supply voltage / at DC:
rated value: 24 V.
: 20.4 ... 28.8 V.
consumed current / at DC:
at 24 V / typical: 0.05 A.
ambient conditions:
ambient temperature:
during operation: -20 ... +70 °C.
during storage: -25... +80 °C.
during transport: -25 ... +80 °C.
protection class IP: IP67.
shock resistance: EN 60721-3-7 Class 7 M2.
shock acceleration: 500 m/s².
vibrational acceleration: 200 m/s².
design, dimensions and weights:
width: 75 mm.
height: 41 mm.
Depth: 75 mm.
net weight: 0.2 kg.
fastening method: 2 x M5 screws.
wire length:
between master and IO-Link device / maximum: 20 m.
product features, product functions, product components / general:
display version: 3-colour LED.
product feature / silicon-free: Yes.
standards, specifications, approvals:
certificate of suitability: Radio according to R&TTE guidelines EN300 330 and EN 301489, FCC, cULus.
certificate of suitability:
IECEx: No.
MTBF: 480 a.
reference code:
according to IEC 81346-2:2019: BYB.
standards, specifications, approvals / Environmental Product Declaration:
Environmental Product Declaration: Yes.
Global Warming Potential [CO2 eq]:
total: 124.25 kg.
during manufacturing: 11.24 kg.
during operation: 112.71 kg.
after end of life: 0.3 kg.
