PB PCF Standard Cable (200/230), plastic, PVC outer sheath, 4x ST, 100 m
SKU: 6XV1821-1BT10
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
PCF Fiber-optic cable with plastic coating, preassembled to your desired length.
PROFIBUS PCF Fiber optic cable with four PCF BFOC connections, 100 m in length.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Suitability for use: Cable for indoor applications.
Wire length: 100 m.
Number of Fibers / per FOC core: 1.
Number of FO cores / per FOC cable: 2.
Version of the FO conductor Fiber: Step index Fiber 200/230 µm.
Outer diameter:
Of the optical Fibers: 200 µm.
Of the optical Fiber sheath: 230 µm.
Of the FOC core sheath: 2.2 mm.
Symmetrical deviation / of the outer diameter of the FOC core sheath: 0.1 mm.
Outer diameter / of the cable: 4.7 mm.
Material:
Of the Fiber-optic cable core: Quartz glass.
Of the optical Fiber sheath: Fluoridated special polymer.
Of the FOC core sheath: PVC.
Of the Fiber-optic cable sheath: PVC.
Of the strain relief: Kevlar Fibers.
Colour:
Of the FOC core sheath: orange/black.
Of cable sheath: Violet.
Bending radius:
With single bend / minimum permissible: 47 mm.
With multiple bends / minimum permissible: 70 mm.
Tensile load:
During installation / short-term: 800 N.
During operation / maximum: 200 N.
Ambient temperature:
During operation: -30 ... +70 °C.
During storage: -30 ... +70 °C.
During transport: -30 ... +70 °C.
During installation: -5 ... +50 °C.
Chemical resistance:
To mineral oil: conditional resistance.
To grease: conditional resistance.
Radiological resistance / to UV radiation: not resistant.
Protection class IP: IP20.
Product feature: silicon-free.
Wire length for POF FOC / with PROFIBUS / maximum: 400 m.
