SIENOPYR FOC ship cable, multi-mode, halogen-free, shipbuilding,
SKU: 6XV1830-0NH10
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Product type designation is SIENOPYR marine duplex fiber-optic cable.
Product Description: Glass fiber optic cable SIENOPYR maritime cable, sold by the meter and unassembled.
FOC SIENOPYR offers fiber-optic cable for maritime and offshore applications. Sold by the meter, with a delivery unit limit of 1000 m and a minimum order quantity of 20 meters.
Suitability for use: Fixed routing on ships and on offshore platforms in all enclosed spaces and on open deck, marine approval available.
Version of the assembled FO cable: sold by the meter.
Cable designation: MI-VHH 2G 62.5/125 3.1B200 + 0.8F600 + 2x1Cu 300V.
Optical data:
Attenuation factor per length:
At 650 nm / maximum: 160 dB/km.
At 850 nm / maximum: 3.1 dB/km.
At 1300 nm / maximum: 0.8 dB/km.
Bandwidth length product:
At 850 nm: 200 GHz·m.
At 1300 nm: 600 GHz·m.
Buy currently uses Select Automation shop pricing and checkout.
Mechanical data:
Number of fibres / per FOC core: 1.
Number of FO cores / per FOC cable: 2.
Version of the FO conductor fibre: Multimode graded-index fibre 62.5/125 µm, OM 1.
Design of the FOC core: Solid core.
Design of the fibre-optic cable: Segment able outer conductor.
Outer diameter:
Of the optical fibres: 62.5 µm.
Of the optical fibre sheath: 125 µm.
Of the FOC core sheath: 2.9 mm.
Outer diameter / of the cable: 13.3 mm.
Symmetrical deviation / of the outer diameter of the line: 0.5 mm.
Material:
Of the fibre-optic cable core: Mineral glass.
Of the FOC core sheath: Polyolefine.
Of the fibre-optic cable sheath: SHF1 mixture.
Of the strain relief: Aramid fibers.
Colour:
Of cable sheath: Black.
Bending radius:
With single bend / minimum permissible: 133 mm.
With multiple bends / minimum permissible: 266 mm.
Tensile load:
During operation / maximum: 250 N.
Weight per length: 220 kg/km.
Ambient conditions:
Ambient temperature:
During operation: -40 ... +80 °C.
During storage: -40 ... +80 °C.
During transport: -40 ... +80 °C.
During installation: -10 ... +50 °C.
ambient condition / for operation: At ambient temperatures below -10 degrees Celsius, the cable must not be subjected to any movements other than the normal vibration levels encountered on board ship.
Fire behaviour: Flame-resistant acc. to IEC 60332-3 (Cat. A).
Chemical resistance:
To water: conditional resistance.
Radiological resistance / to UV radiation: Resistant.
Product features, product functions, product components / general:
Product feature:
Halogen-free: Yes.
Silicon-free: Yes.
Product component / rodent protection: No.
Wire length:
For glass FOC / for 100BaseFX / for Industrial Ethernet / maximum: 4000 m.
For glass FOC / for 1000BaseSX / for Industrial Ethernet / maximum: 350 m.
For glass FOC / for 1000BaseLX / for Industrial Ethernet / maximum: 550 m.
For glass FOC / with PROFIBUS / maximum: 3000 m.
Standards, specifications, approvals:
Certificate of suitability:
RoHS conformity: Yes.
Marine classification association:
French marine classification society (BV): Yes.
Det Norske Veritas (DNV): Yes.
Germanische Lloyd (GL): Yes.
Lloyds Register of Shipping (LRS): Yes.
Reference code:
According to IEC 81346-2: WH.
According to IEC 81346-2:2019: WHA.
