FO robust cable GP 50/125/190 (OM 2), multimode, 2x LC duplex plugs, UL, 1 m
SKU: 6XV1873-5RH10
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Glass Fiber optic cable that has been preassembled to the length you request.
FO robust cable GP 50/125, pre-assembled with two LC Duplex connections, 1.0 m in length.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Waterproof cable (lengthwise and sideways) with non-metallic protection against rodents for use indoors and outdoors as well as for direct routing underground.
Wire length: 1 m.
Number of Fibers / per FOC core: 1.
Number of FO cores / per FOC cable: 2.
Version of the FO conductor Fiber: Multi-mode gradient Fiber 50/125/245 µm, OM2.
Design of the FOC core: Solid core, diameter 900 µm.
Design of the Fiber-optic cable: segment able.
Outer diameter:
Of the optical Fibers: 50 µm.
Of the optical Fiber sheath: 125 µm.
Of the FOC core sheath: 2.2 mm.
Outer diameter / of the cable: 7.5 mm.
Material:
Of the Fiber-optic cable core: Quartz glass.
Of the optical Fiber sheath: Quartz glass.
Of the FOC core sheath: PE flame retardant.
Of the Fiber-optic cable sheath: PE flame retardant.
Of the strain relief: Aramid Fibers and glass roving.
Colour:
Of the FOC core sheath: orange/black, with direction arrow.
Of cable sheath: black.
Bending radius:
With single bend / minimum permissible: 25 mm.
With multiple bends / minimum permissible: 40 mm.
Tensile load:
During installation / short-term: 2000 N.
During operation / maximum: 1000 N.
Ambient temperature:
During operation: -40 ... +70 °C.
During storage: -40 ... +70 °C.
During transport: -40 ... +70 °C.
During installation: -20 ... +60 °C.
Chemical resistance:
To mineral oil: conditional resistance.
To grease: conditional resistance.
To water: resistant.
Radiological resistance / to UV radiation: resistant.
Product feature:
Halogen-free.
Silicon-free.
Wire length:
For glass FOC / for 100BaseFX / for Industrial Ethernet / maximum: 5000 m.
For glass FOC / for 1000BaseSX / for Industrial Ethernet / maximum: 750 m.
For glass FOC / for 1000BaseLX / for Industrial Ethernet / maximum: 2000 m.
For glass FOC / with 10GBaseSR / for Industrial Ethernet / maximum: 60 m.
For glass FOC / with PROFIBUS / maximum: 3000 m.
