POF Standard Cable GP 980/1000, with poly-optic fibers, UL, sold by the meter
SKU: 6XV1874-2A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Unassembled Fiber-optic cable with polypoidal Fiber for sale by the meter.
POF Standard Cable GP 980/1000 PROFINET, standard cable.
Minimum order quantity of 20 m and maximum length of 500 m. Sold by the meter.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Suitability for use: Cable for permanent installation indoors, UL approval.
Number of Fibers / per FOC core: 1.
Number of FO cores / per FOC cable: 2.
Version of the FO conductor Fiber: POF FOC 980/1000 µm.
Outer diameter:
Of the optical Fibers: 980 µm.
Of the optical Fiber sheath: 1000 µm.
Of the FOC core sheath: 2.2 mm.
Symmetrical deviation / of the outer diameter of the FOC core sheath: 0.1 mm.
Outer diameter / of the cable: 7.8 mm.
Material:
Of the Fiber-optic cable core: Polymethylmethacrylate (PMMA).
Of the optical Fiber sheath: Fluoridated special polymer.
Of the FOC core sheath: PA.
Of the Fiber-optic cable sheath: PVC.
Of the strain relief: Kevlar fibers.
Colour:
Of the FOC core sheath: orange/black.
Of cable sheath: green.
Bending radius:
With single bend / minimum permissible: 100 mm.
With multiple bends / minimum permissible: 150 mm.
Tensile load:
During installation / short-term: 100 N.
During operation / maximum: 100 N.
Ambient temperature:
During operation: -30 ... +70 °C.
During storage: -30 ... +70 °C.
During transport: -30 ... +70 °C.
During installation: 50 °C.
Chemical resistance:
To mineral oil: conditional resistance.
To grease: conditional resistance.
Radiological resistance / to UV radiation: not resistant.
Product feature: silicon-free.
Wire length:
For POF FOC / for Industrial Ethernet / maximum: 50 m.
