DRM570012

Specifications dimensions and weights: Depth: 35.7 mm. Depth (inches): 1.406 inch. Height: 27.4 mm. Height (inches): 1.079 inch. Width: 21 mm. Width (inches): 0.827 inch. Net weight: 36.2 g. Temperatures: Storage temperature: -40 °C - 70 °C. Operating temperature: -40 °C - 55 °C. Humidity: 35 - 85 % rel. humidity, no condensation. Environmental Product Compliance: REACH SVHC: /. Rated data UL: Certificate No. (cURus): E312083. Control side: Rated control voltage: 12 V DC. Rated current DC: 75 mA. Power rating: 0.9 W. Coil resistance: 160 Ω ± 10 %. Coil tolerance: 10 %. Status indicator: No. Load side: Rated switching voltage: 250 V AC. Continuous current: 5 A. Max. switching frequency at rated load: 0.1 Hz. Max. switching voltage, AC: 250V. Min. switching power: 10 mA @ 12 V, 100 mA @ 5 V. Inrush current: 10 A / 50 ms. AC switching capacity (resistive), max.: 1250 VA. DC switching capacity (resistive), max.: 120 W @ 24 V. Switch-on delay: < 20 ms. Switch-off delay: < 20 ms. Contact type: 4 CO contact (AgNi flash gold-plated). Mechanical service life: 20 x 106 switching cycles. General data: Test button available: No. Mechanical switch position indicator: Yes. Colour: Transparent. UL94 flammability rating component: Component: Relay cover. UL94 flammability rating: V-2. Component: Relay baseplate. UL94 flammability rating: V-0. Component: Relay status indicator. UL94 flammability rating: HB. Insulation coordination: Rated voltage: 250 V. Pollution severity: 2. Surge voltage category: III. Clearance and creepage distances for control side - load side: ≥ 5.5 mm. Dielectric strength for control side - load side: 1.8 kVeff /1 min. Dielectric strength of neighbouring contacts: 1 kVeff / 1 min. Dielectric strength of open contact: 1 kVeff / 1 min. Impulse withstand voltage: 6 kV (1.2/50 µs). Protection degree: IP20. Further details of approvals / standards: Certificate No.(cURus): E312083. Connection data: Wire connection method: Plug-in connection.
