Solenoid coil, VACN-H1-A1-1

Specifications • Solenoid coils VACN-H1, Without plug socket, plug pattern to EN 175301-803, type A • Mounting position optional • Switching position indicator no • Min. pick-up time 12 ms • Duty cycle 100% • Power factor (cos phi) 0.7 • Characteristic coil data 24 V DC: 11.9 W • Permissible frequency fluctuations +/- 10% • Permissible voltage fluctuations +/- 10 % • Restrictions for environmental and media temperature (with limited duty cycle) -20 ... 60° C • Corrosion resistance class CRC 4 - Very high corrosion stress • LABS (PWIS) conformity VDMA24364 zone III • Degree of protection IP65 • Note on degree of protection In assembled state • Ambient temperature -20 °C ... 50 °C
