Filter flow control, CAMF-C6-FD-C6-11A
SKU: 8096867
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Specifications
• Servo drive CMMT-AS
• Electrical accessories for motor controllers, Filter flow control
• Short circuit current rating no
• Current rating at 40° C 6 A
• Operational voltage range AC 0 V ... 600 V
• Nominal inductance 3.7 mH
• Nominal inductance tolerance 10 %
• Mains frequency 50 Hz ... 60 Hz
• Insulation voltage 4000 V
• Dimensions (W x L x H) 60 x 80 x 116 mm
Buy currently uses Select Automation shop pricing and checkout.
Servo drive CMMT-AS
• Compact servo drive for point-to-point and interpolating motion, suitable for various Ethernet-based bus systems and can be integrated directly into system environments of different control manufacturers.
• One of the most compact servo drives on the market
• Precise force, speed and position control
• Auto-tuning supports easy commissioning and automatically optimises the control behaviour of rotary and linear motions
• The latest generation of servo drive systems with optimised prices and sizes
• With safety functions
• Configuration of standard safety functions without software
• MP variant with multi-protocol: the required bus protocol can be selected using the commissioning software Festo Automation Suite or directly on the servo drive
• Optimally with servo motor EMMT-AS
• Universal applications
• Sustainable operation thanks to energy recovery
