Integrated signal lamp, continuous light 12-230 V UC green
SKU: 8WD5300-1AC
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Integrated signal lamp with continuous illumination, green, 12-230 V AC/DC, diameter 70 mm.
General technical data:
Product designation: Continuous light element.
Type of voltage of the operating voltage: AC/DC.
Operating voltage:
At DC rated value: 12 ... 230 V.
At AC at 50 Hz rated value: 12 ... 230 V.
At AC at 60 Hz rated value: 12 ... 230 V.
Relative positive tolerance of the operating voltage: 10 %.
Relative negative tolerance of the operating voltage: -10 %.
Consumed active power: 5 W.
Reference code according to IEC 81346-2: P.
Fastening method: Bayonet / flush mounting.
Material: PC; PC/ABS; PA.
Colour: green.
Buy currently uses Select Automation shop pricing and checkout.
Mechanical data:
Product component light source: No.
Type of electrical connection: screw terminal.
Outer diameter of the signal column element: 75 mm.
Lamp:
Socket design: BA 15d.
Design of the optical signal: continuous light.
Type of light source: filament lamp / LED.
Ambient conditions:
Ambient temperature during operation: -20 ... +60 °C.
Protection class IP: IP65.
Depth: 31 mm.
Height: 66 mm.
Width: 75 mm.
