GREEN LED + DIODE MODULE 28-60VDC
SKU: 9902906099
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Socket modules in Series 99:
Plug-in modules are useful add-ons for relays that provide timing, diode protection, RC circuits,
LED indication (for observing relay status from a distance), bypass, and all socket-mounted plug-in relay features.
The modules improve the functioning of the relay by only plugging them into designated sockets.
Buy currently uses Select Automation shop pricing and checkout.
Depending on the chosen module, they can offer:
Coil back emf suppression during switch-off LED indication to indicate whether the coil is activated.
Placed across the coil terminals to provide protection from reverse polarization.
Distressing leakage currents in the coil circuit are bypassed.
LED + diode module:
Recovery diode + LED module is used for DC, reverse voltage peaks are short circuited by the recovery diode (positive to terminal A1), release time is increased by approximately 3 times if this is undesirable use a varistor or RC module.
LED indicator illuminates when coil is energised.
VOLTAGE: 28 - 60 VDC
DESCRIPTION: Plug-in led + diode indicating module for sockets.
LED COLOUR: Green
