Remote Module(RS-485), 4DI, 8AI(0-10V)-16bits
SKU: A-1020
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
A-10x RS-485 I/O module, support protocol:
LED
DC Power, Remote Modules ADIO
8AI (0~10V) - 16 bits, 4DI
RS-485*1, isolated
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Operation Voltage: 10~30VDC / 24VAC
Communication Baud Rate: 2400~921600bps
Isolation: YES (5000VDC)
Input Operating Frequency: 10HZ.
Output Operating Frequency: Transistor: 10HZ.
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Installation: 35 mm DIN rail or Flush mounting
Dimension (W x H x D mm): 76.4*118.2*38.5 mm
Analog Inputs: 8 (16-bit)
Analog Input Type: 0/2~10V
Analog Input / Output Accuracy: ±0.1% / ±1%
Interface: RS-485 + USB
Channel Independent Configuration: YES
Sampling Rate: 10 sample/second (total)
Inputs:
4*Isolation DI
Status low: < 1VDC
Status high: > 5~30VDC
