Sensor-Arduino Flame
SKU: ARD-0022-G01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The KY-026 Flame Sensor Module detects flames via infrared and is intended for use with Arduino and other microcontroller applications.
It detects infrared radiation emitted by flames and produces both analogue and digital signals.
An integrated potentiometer adjusts the digital detection threshold, making the module appropriate for flame detection, alarm systems, and fire-monitoring prototypes.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: Flame Sensor Module.
Sensor Type: Infrared Flame Sensor.
Detection Principle: Infrared radiation detection.
Typical Detection Wavelength: 760–1100 nm.
Operating Voltage: 3.3–5 V DC.
Output Type: Analog and Digital.
Analog Output: AO.
Digital Output: DO.
Digital Threshold: Adjustable.
Sensitivity Adjustment: Onboard potentiometer.
Interface: VCC / GND / AO / DO.
Number of Pins: 4.
Comparator: LM393.
Indicator: Onboard LED.
Detection Angle: 60°.
Compatible Platforms: Arduino, ESP32, ESP8266, Raspberry Pi, STM32 and other microcontroller platforms.
Applications: Flame detection, fire alarm prototypes, safety monitoring, robotics, automation, Arduino projects and DIY electronics.
