XH-M404 DC 4-40V 8A Digital Display Voltage Regulator Module XL4016E1
SKU: ARD-0095-M01
Out of stock
* Online sales only
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
The voltage rating of this XL4016E1 Step-Down Power Supply Module is 4-40VDC to 1.25-36VDC.
The highest power rating for this module is 200W.
An external fan mounted on the heatsinks to cool the integrated circuit can raise the module's output current to 8A.
Remaining stock can still be purchased. We can quote on an alternative or replacement product.
View recommended replacementRequest a backorder quote. We will confirm price and lead time before payment.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Range of input voltage: 4V–40V DC.
Adjustable 1.25V–36V DC output voltage range.
Current output: 0–8 A.
200W of output power with up to 94% efficiency.
The integrated thermal shutdown mechanism.
Integrated current limit function.
Short output protection mechanism built-in.
