TP4056 USB Type-C Lithium Battery Charger Module with Protection
SKU: ARD-0129-L01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The TP4056 USB Type-C Lithium Battery Charger Module with Protection is a compact charging solution designed for single-cell lithium-ion or lithium-polymer batteries.
Featuring a USB Type-C input, it provides convenient modern connectivity while integrating overcharge, over-discharge, and short-circuit protection.
With its built-in TP4056 IC, the module ensures safe, efficient charging and battery management, making it ideal for DIY electronics, portable devices, and embedded systems.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: Lithium Battery Charger & Protection Module.
Controller IC: TP4056.
Battery Type: Single-cell Li-ion / Li-Po.
Nominal Battery Voltage: 3.7 V.
Full Charge Voltage: 4.2 V.
Battery Configuration: 1S.
Input Connector: USB Type-C.
Input Voltage: 5 V DC.
Charging Method: Constant Current / Constant Voltage (CC/CV).
Typical Charging Current: Up to 1 A.
Protection: Overcharge, over-discharge, over-current and short circuit.
Charging Indicator: LED.
Full-Charge Indicator: LED.
Battery Connection: B+ / B−.
Protected Output: OUT+ / OUT−.
Module Type: PCB Battery Charger / Protection Module.
Applications: Rechargeable battery packs, portable electronics, Arduino projects, IoT devices, LED projects, robotics and DIY battery-powered equipment.
