VL53L1X Time-of-Flight (ToF) Laser Distance Sensor Module (4 m, I²C)
SKU: BRD-0042-H14
Sold by Select Automation
Final price R 143.75
R 125.00 excl. VAT
Availability: In Stock (9 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The VL53L1X Time-of-Flight (ToF) Distance Sensor Module is a high-performance laser ranging sensor capable of measuring distances up to 4 metres accurately and without contact.
STMicroelectronics FlightSense™ technology calculates the time it takes for an emitted infrared laser pulse to reflect from an object and return to the sensor, resulting in precise distance readings regardless of target color or reflectivity.
The sensor uses a standard I²C interface and works with Arduino, Raspberry Pi, ESP32, ESP8266, STM32, and other microcontroller platforms.
With its compact design, quick measurement rate, and customizable field of view, the VL53L1X is perfect for robotics, obstacle detection, gesture recognition, automation, and IoT applications.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: Time-of-Flight (ToF) Distance Sensor Module.
Sensor IC: STMicroelectronics VL53L1X.
Measurement Technology: Infrared Laser Time-of-Flight (940 nm, Class 1 Laser).
Measurement Range: 40 mm – 4000 mm (4 m).
Resolution: 1 mm.
Measurement Frequency: Up to 50 Hz.
Operating Voltage (Sensor): 2.6–3.5 V DC.
Operating Voltage (Typical Module): 3.3–5 V DC.
Interface: I²C (Up to 400 kHz).
Default I²C Address: 0x52.
Operating Temperature: -20°C to +85°C.
Laser Wavelength: 940 nm (Class 1 Eye Safe).
Package Size (Sensor): 4.9 × 2.5 × 1.56 mm.
