MPU6500 6-Axis Accelerometer & Gyroscope Motion Sensor Module
SKU: BRD-0043-H14
Sold by Select Automation
Final price R 80.50
R 70.00 excl. VAT
Availability: In Stock (10 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The MPU6500 is a high-performance 6-axis motion tracking sensor that combines a 3-axis gyroscope and a 3-axis accelerometer into a compact device.
TDK InvenSense designed it with integrated 16-bit ADCs, a Digital Motion Processor (DMP®), and a 512-byte FIFO buffer for efficient motion data processing with reduced microcontroller workload.
The MPU6500 supports I²C and SPI communication interfaces and is widely utilized in robotics, drones, balancing robots, gaming controllers, wearable devices, IoT systems, and embedded motion sensing applications.
Its low power consumption, high accuracy, and programmable measurement ranges make it perfect for precise orientation and motion detection applications.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: 6-Axis MEMS Motion Tracking Sensor.
Model: MPU6500.
Manufacturer: TDK InvenSense.
Motion Sensors:
3-Axis Accelerometer.
3-Axis Gyroscope.
Accelerometer Ranges: ±2g, ±4g, ±8g, ±16g.
Gyroscope Ranges: ±250, ±500, ±1000, ±2000°/s.
ADC Resolution: 16-bit.
Communication Interface: I²C and SPI.
FIFO Buffer: 512 Bytes.
Digital Motion Processor (DMP): Integrated.
Integrated Temperature Sensor: Yes.
Supply Voltage (VDD): 1.71V–3.45V.
Logic Voltage (VDDIO): 1.71V–3.45V.
Gyroscope Output Rate: Up to 8 kHz.
Accelerometer Output Rate: Up to 4 kHz.
Operating Temperature: -40°C to +85°C.
