EasyPact TVS contactor 3P(3 NO)
SKU: CBI-0005-H08
Sold by Select Automation
Final price R 456.78
R 397.20 excl. VAT
Availability: In Stock (1 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The EasyPact TVS Contactor 3P (3 NO) - AC-3 - <= 440 V 9A - 110 V AC coil, LC1E0910F5, is a reliable and durable contactor for motor control applications.
The range is renowned for its ease of installation and operation.This contactor is suited for use in electro-domestic and HVAC systems, and it offers a low-cost solution for basic control duties.
It has a 110 V AC coil and is rated for a maximum operational voltage of 440 V AC and current of 9A.
The contactor is designed to survive hostile environments and has great electrical and mechanical strength.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Poles: 3P (3 NO).
Utilization Category: AC-3.
Rated Operational Voltage: <= 440 V AC.
Rated Operational Current: 9 A.
Control Circuit Voltage: 110 V AC.
Rated Making Capacity: 320 A at 440 V AC.
Rated Breaking Capacity: 256 A at 440 V AC.
Short-Time Withstand Current: 260 A at 40 °C for 10 seconds.
Average Impedance: 2.5 mOhm.
Rated Insulation Voltage: 690 V.
Overvoltage Category: III.
Pollution Degree: 3.
Mechanical Durability: 8,000,000 cycles.
Electrical Durability: 5,000,000 cycles.
Operating Temperature Range: -5°C to 55°C.
Mounting: DIN-rail.
Compliance: IEC, CCC, EAC certified, Green Premium compliant (RoHS/REACH).
