CBI245A Battery charger UPS backup charging module power supply in one unit
SKU: CBI245A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Technical features:
Power management will be able to be optimized because of the all-in-one units (DC-UPS).
The maximum possible current on the load output is equal to double the device's rated current input.
Battery faults such as sulfation, short circuits, unintentional reverse polarity connections, and battery disconnection can be easily identified and eliminated with the aid of the Blink Code of Diagnosis LED during installation and after sale by the Real Time Auto-diagnostic system.
Continuous monitoring of battery efficiency decreases the danger of battery damage and enables safe operation in a permanent connection.
The user has the option to switch them to a single charging level; however, they are designed for two charging levels: boost and charge.
The sturdy enclosure, which includes a DIN rail mounting bracket, provides IP20 protection.
Buy currently uses Select Automation shop pricing and checkout.
General Information:
Voltage of insulation (in/out): 3000 Vac.
Insulation voltage (input/earth, PE): 2000 Vac.
Insulation voltage (out load, battery, and earth, PE): 500 Vac.
Insulation voltage: 500 Vac for the main or backup terminal, the fault system, the battery, and the outload.
Protection Class (EN/IEC 60529): IP20.
Reliability: MTBF IEC 61709 > 300,000 h.
Environment Pollution Degree: 2.
Screw Type for Connection Terminal Blocks: 2.5 mm (24–14AWG).
Protection class (PE Connected): I with PE.
Dimensions (W x H x D): 65x115x135 mm.
Weight: around 0.6 kg.
Input data:
Voltage range for nominal input: 115–230–277.
Range of voltage (Vac): 90 ÷ 305.
Inrush Current (Vn-In nom. load) I²t: <11 A < 5 msec.
Frequency: 47/63 Hz.
Maximum Input Current (115–230–277 Vac): 2.8–1.7–1.3 A.
Internal fuse (not replaceable): 4A.
External fuse (recommended) Curve B of MCB: 10 A.
Output Data (Internal Power Supply):
Output voltage (Vn) and nominal current (In): 24 VDC / 5 A.
Output current In = iload: 5 A.
Efficiency (at 50% of the rated current): > 90%.
Residual ripple: < 60 mVpp.
Turn-on delay after applying mains voltage: 1 second (maximum).
Startup with a strong load (capacitive load): Yes, unlimited.
Maximum power load dissipation (W): 17.
Short Circuit Current Icc. Maximum 2 seconds: Hiccup mode at 60°C. Automatic restart: In x 3.5.
Protection against overload: Yes.
Protection against overvoltage output: Yes (typ. 35 Vdc).
Thermal Protection from Overheating: Yes.
