HGH20CA Block for Linear Rail, HGR20
SKU: CNC-0012-P02
Sold by Select Automation
Final price R 598.31
R 520.27 excl. VAT
Availability: In Stock (20 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The "HGH20CA bearing block" is a component that slides along an "HGR20 linear rail."
It is a square-type bearing block designed to carry heavy loads with smooth linear motion, commonly used in CNC machines, 3D printers, and automation systems.
The "HGH" refers to the block shape, "20" is the rail width in millimeters, and "CA" signifies the heavy-duty configuration.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Block type: HGH (Square-type, heavy load)
Model number: HGH20CA
Rail size: 20mm width (HGR20)
Load type: Heavy load
Accuracy class: Available in various precision grades (C, H, P, SP, UP)
Block dimensions:
Length: ~90 mm
Width: ~63 mm
Height: ~30 mm
Mounting hole dimensions: 4 x M6 threads
Number of ball circuits: 4 or more, for smooth motion
Material: High-strength steel
Sealing: Dual rubber seals for dust and debris protection
Preload options: Zero to heavy preload, depending on application
Operating temperature: Typically up to 80°C
