Bearing block set for SFU20 FK15 & FF15
SKU: CNC-0038-P02
Sold by Select Automation
Final price R 1,553.41
R 1,350.79 excl. VAT
Availability: In Stock (5 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
A "Bearing block set for SFU20 FK15 & FF15" is a pair of support bearings designed for SFU20 ball screws (20mm diameter).
The set includes an FK15 fixed-end support bearing and an FF15 floating-end support bearing.
The FK15 is mounted at the motor (fixed) side, while the FF15 supports the free end, allowing axial movement and proper alignment.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
FK15 (Fixed-end bearing):
Bearing type: Angular contact bearing
Internal bearing model: Typically 7202 or 7203
Mounting holes: 4 holes
Mounting pattern: Square
Application: Fixed support at the motor side
FF15 (Floating-end bearing):
Bearing type: Deep groove ball bearing
Internal bearing model: Typically 6002 or 6003
Mounting holes: 4 holes
Mounting pattern: Square
Application: Free-end support allowing axial movement
Compatibility: For SFU2004, SFU2005 ball screws (20mm diameter)
Material: Steel or aluminum
Precision: High, enabling smooth and accurate linear motion
Dimensions: FK15 and FF15 typically have matching outer dimensions but different internal bearing configurations
