Molex Female Pins
SKU: CON1-0006-000
Sold by Select Automation
Final price R 3.57
R 3.10 excl. VAT
Availability: In Stock (31 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The Molex 02-09-1104 is a female crimp terminal contact that is used to terminate electrical lines and is compatible with Molex STANDARD.093" connector housings.
It is the female equivalent of the male crimp terminal used in the matching connection system.
The terminal features a brass contact with tin coating, accepts 20-14 AWG wire (0.5-2mm²), and has a maximum contact resistance of 10mΩ.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: Crimp Terminal Contact.
Gender: Female.
Termination Style: Crimp.
Wire Size: 20AWG to 14AWG.
Wire Cross-Section: 0.5–2mm².
Compatible Housing: Molex STANDARD .093" Connector Housing.
Contact Diameter: 2.36mm.
Contact Material: Brass.
Contact Plating: Tin.
Maximum Contact Resistance: 10mΩ.
Operating Temperature: -40°C to +105°C.
Application: Wiring harnesses, industrial automation, consumer electronics, computers, communications and security systems.
