EDAC 516 Series Female Crimp Terminal Contact 8.5A (100pcs)
SKU: CON1-0057-000
Sold by Select Automation
Final price R 1,297.51
R 1,128.27 excl. VAT
Availability: In Stock (16 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The EDAC 516 connection is a loose female crimp terminal contact that is compatible with the EDAC 516 Series connector housing.
The contact is crimped onto a wire and put into the connector housing to form a secure and dependable electrical connection.
It is appropriate for multipole connector systems used in industrial, automotive, and railroad signalling, control, and testing applications.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: crimp terminal contact.
Gender: Female.
Termination Style: Crimp.
Mounting Type: Cable / Wire mount.
Orientation: Straight.
Current Rating: 8.5A.
Wire Size: 28AWG to 18AWG.
Contact Material: Phosphor Bronze.
Contact Plating: Gold over Nickel.
Maximum Contact Resistance: 10mΩ.
Operating Temperature: -65°C to +105°C.
Compatible Connector System: EDAC 516 Series.
Application: Industrial control, railway signalling, automotive systems, test equipment and multipole cable connections.
