HIF3B Series 2.54mm Pitch Cable Mount IDC Connector, Socket, 10 Way, 2 Row
SKU: CON10-0004-000
Sold by Select Automation
Final price R 3.22
R 2.80 excl. VAT
Availability: In Stock (8 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The Hirose HIF3B Series 10-way IDC connector is a female cable-mount socket used to terminate 28AWG flat ribbon cables.
It has ten contacts grouped in two rows with a 2.54mm pitch and employs IDC termination, which allows ribbon cable conductors to be attached without stripping individual wires.
The connector has a shrouded shell with polarizing characteristics to aid in proper mating and prevent wrong insertion.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: IDC Connector Socket.
Gender: Female.
Number of Contacts: 10.
Number of Rows: 2.
Pitch: 2.54mm.
Mounting Type: Cable Mount.
Orientation: Straight.
Termination Style: IDC.
Compatible Cable: 28AWG flat ribbon cable.
Rated Current: 1A.
Rated Voltage: 200V AC.
Contact Material: Beryllium Copper Alloy.
Contact Plating: Gold.
Housing Material: PBT (Polybutylene Terephthalate).
Housing: Shrouded.
Operating Temperature: -55°C to +85°C.
Features: Polarised design and mis-insertion prevention.
Application: Ribbon cable assemblies, electronic equipment, control systems and PCB interconnections.
