2EDGVC-5.08-12 12 way Vertical Connector
SKU: CON12-0006-000
Sold by Select Automation
Final price R 26.76
R 23.27 excl. VAT
Availability: In Stock (9 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 2EDGVC-5.08-12 is a 12-way vertical pluggable terminal block connector that provides secure and dependable wire-to-board connections in industrial and commercial electronic applications.
This connector, with a 5.08 mm pitch and 12-position arrangement, provides a reliable plug-in interface for PCB-mounted terminal headers, enabling for quick installation, simple maintenance, and easier field wiring.
The connector, made of UL94 V-0 flame-retardant PA66 with tin-plated copper alloy contacts, has high electrical conductivity, tight screw-clamp wire termination, and long-lasting durability.
Its pluggable architecture allows for quick replacement and servicing without affecting field wiring.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: Pluggable Terminal Block Connector.
Model: 2EDGVC-5.08-12.
Number of Positions: 12 Way.
Pitch: 5.08 mm.
Orientation: Vertical.
Connection Type: Screw Clamp.
Mounting Type: Plug-In.
Wire Size: 0.2–2.5 mm² (24–12 AWG).
Rated Current: Up to 15 A.
Rated Voltage: Up to 300 V AC.
Contact Material: Tin-Plated Copper Alloy.
Housing Material: PA66 Thermoplastic, UL94 V-0 Flame-Retardant.
Operating Temperature: -40°C to +105°C.
Colour: Green.
RoHS Compliant: Yes.
