5.08mm Pitch, 2 Way, 1 Row, Right Angle PCB Terminal Block Header, Through Hole
SKU: CON2-0016-000
Sold by Select Automation
Final price R 8.60
R 7.48 excl. VAT
Availability: In Stock (39 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 5.08mm Pitch 2-Way Right Angle PCB Terminal Block Header is a durable through-hole board-mounted header that allows for safe, detachable wire-to-board connections.
With a 2-position, single-row layout and a 90° right-angle orientation, it allows for easy horizontal cable input while saving vertical space on the PCB.
This PCB header, designed to work with compatible 5.08 mm pluggable terminal blocks, offers a dependable, high-current connection for industrial, commercial, and electronic applications.
Its flame-retardant PA66 construction and tin-plated copper alloy connections provide good electrical performance, durability, and a long service life.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: PCB Terminal Block Header.
Number of Positions: 2 Way.
Rows: 1.
Pitch: 5.08 mm.
Orientation: 90° Right Angle.
Mounting Type: Through-Hole PCB.
Termination: PCB Solder Pins.
Connection Type: Plug-In Header.
Rated Current: 15 A.
Rated Voltage: 300 V AC.
Contact Material: Tin-Plated Copper Alloy.
Housing Material: PA66, UL94 V-0 Flame-Retardant.
Operating Temperature: -40°C to +105°C.
RoHS Compliant: Yes.
