5.08-301-2P Screw Terminal Block Connector 5mm Pitch 2 Way Blue
SKU: CON2-0023-000
Price on request
Availability: In Stock (80 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 5.08-301-2P Screw Terminal Block Connector is a strong 2-way PCB terminal block that ensures secure and dependable wire-to-board connections.
With a 5.0 mm (5.08 mm compatible) pitch and a 2-position layout, this through-hole terminal block is a solid choice for power and signal wiring in industrial, commercial, and electronic applications.
The screw-clamp termination provides a solid, vibration-resistant connection while accepting a wide range of wire sizes.
The connector is made of UL94 V-0 flame-retardant PA66 with tin-plated copper alloy contacts. It has outstanding electrical conductivity, mechanical durability, and a long service life.
Its blue enclosure allows for easy identification in PCB assemblies.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: PCB Screw Terminal Block.
Model: 5.08-301-2P.
Number of Positions: 2 Way.
Pitch: 5.0 mm (5.08 mm Compatible).
Orientation: Straight (Vertical).
Mounting Type: Through-Hole PCB.
Termination Type: Screw Clamp.
Wire Size: 0.2–2.5 mm² (24–12 AWG).
Rated Current: Up to 15 A.
Rated Voltage: Up to 300 V AC.
Contact Material: Tin-Plated Copper Alloy.
Housing Material: PA66 Thermoplastic, UL94 V-0 Flame-Retardant.
Colour: Blue.
Operating Temperature: -40°C to +105°C.
RoHS Compliant: Yes.
