5.08mm Pitch, 2 Way, 1 Row, Straight PCB Terminal Block Header, Through Hole
SKU: CON2-0027-000
Sold by Select Automation
Final price R 8.07
R 7.02 excl. VAT
Availability: In Stock (2 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 5.08mm Pitch 2-Way Straight PCB Terminal Block Header is a dependable wire-to-board PCB connector that allows for secure and detachable connections in industrial and commercial electronic applications.
This straight (vertical) through-hole PCB header has a 2-position, single-row layout with a 5.08 mm pitch and matches with suitable pluggable terminal block plugs to offer a reliable power or signal connection.
This PCB header, made of tin-plated copper alloy contacts and a UL94 V-0 flame-retardant PA66 housing, provides outstanding electrical conductivity, mechanical durability, and long-term reliability.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: PCB Terminal Block Header.
Number of Positions: 2 Way.
Configuration: 1 Row.
Pitch: 5.08 mm.
Orientation: Straight (Vertical).
Mounting Type: Through-Hole PCB.
Termination: Solder.
Connection Type: Wire-to-Board.
Compatible Connector: 5.08 mm Pitch Pluggable Terminal Block Plug.
Rated Current: Up to 15 A.
Rated Voltage: Up to 300 V AC.
Contact Material: Copper Alloy.
Contact Finish: Tin Plated.
Housing Material: PA66 Thermoplastic, UL94 V-0 Flame-Retardant.
Operating Temperature: -40°C to +105°C.
Colour: Green.
RoHS Compliant: Yes.
