2-Way 5.08mm picth PCB Header Block 90 Degree
SKU: CON2-0030-000
Price on request
Availability: In Stock (34 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 2-Way 5.08mm Pitch PCB Header Block, 90° Right Angle is a sturdy wire-to-board PCB terminal header intended for secure and dependable pluggable connections in industrial and commercial electronic applications.
This right-angle through-hole PCB header, with a 2-position, single-row layout and a 5.08 mm pitch, offers a compact option for horizontal cable routing and is compatible with 5.08 mm pluggable terminal block plugs.
The header's tin-plated copper alloy contacts and UL94 V-0 flame-retardant PA66 housing provide good electrical conductivity, mechanical strength, and long-term durability.
It’s through-hole installation provides a strong PCB connection, making it appropriate for power and signal applications.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: PCB Terminal Block Header.
Number of Positions: 2 Way.
Configuration: 1 Row.
Pitch: 5.08 mm.
Orientation: Right Angle (90°).
Mounting Type: Through-Hole PCB.
Termination: Solder.
Connection Type: Wire-to-Board.
Compatible Connector: 5.08 mm Pitch Pluggable Terminal Block Plug.
Rated Current: Up to 15 A.
Rated Voltage: Up to 300 V AC.
Contact Material: Copper Alloy.
Contact Finish: Tin Plated.
Housing Material: PA66 Thermoplastic, UL94 V-0 Flame-Retardant.
Operating Temperature: -40°C to +105°C.
Colour: Green.
RoHS Compliant: Yes.
