20W IDC Socket and Strain Relief
SKU: CON20-0002-000
Sold by Select Automation
Final price R 2.16
R 1.88 excl. VAT
Availability: In Stock (34 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 20-Way IDC Socket with Strain Relief is a ribbon cable connector that allows for the fast and reliable termination of 20-way flat ribbon cables.
The conventional 2.54 mm pitch and 2 × 10 contact layout allow for compatibility with usual 20-way IDC box headers found on PCBs and development boards.
The connector employs Insulation Displacement Contact (IDC) technology, which enables the ribbon cable to be terminated without stripping individual wires.
An incorporated strain relief clip clamps the cable, increasing mechanical strength and shielding the termination from vibration and cable movement.
It is suitable for usage in industrial control systems, embedded electronics, test equipment, and computer peripherals.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: IDC Ribbon Cable Socket.
Connector Type: IDC Socket with Strain Relief.
Number of Positions: 20.
Configuration: 2 × 10 (Dual Row).
Pitch: 2.54 mm (0.1").
Cable Type: 20-Way Flat Ribbon Cable.
Termination Method: Insulation Displacement Contact (IDC).
Mating Connector: 20-Way IDC Box Header.
Contact Material: Phosphor Bronze.
Contact Plating: Tin Plated.
Housing Material: High-Temperature Thermoplastic (UL94 V-0).
Strain Relief: Integrated Clip.
Rated Current: 1 A per contact.
Rated Voltage: 250 V AC/DC.
Contact Resistance: ≤20 mΩ.
Insulation Resistance: ≥1000 MΩ.
Dielectric Withstanding Voltage: 500 V AC for 1 minute.
Operating Temperature: -40°C to +105°C.
RoHS Compliant: Yes.
