5.08 3 Way Right Angle Plug
SKU: CON3-0021-000
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 5.08mm Pitch 3-Way Right Angle Pluggable Terminal Block Plug is a reliable wire-to-board connector that allows for secure and detachable power and signal connections.
This pluggable terminal block, with its 3-position layout, 5.08 mm pitch, and right-angle cable entry, is an effective alternative for PCB-mounted terminal headers when horizontal wire routing is desirable.
The screw-clamp termination offers great wire retention and consistent electrical performance, while the pluggable design allows for quick installation, simple maintenance, and replacement without disrupting field wiring.
It is made of UL94 V-0 flame-retardant PA66 with tin-plated copper alloy connections and is ideal for industrial and commercial electronic applications.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: Pluggable Terminal Block Plug.
Number of Positions: 3 Way.
Pitch: 5.08 mm.
Orientation: Right Angle.
Connection Type: Screw Clamp.
Mounting Type: Plug-In.
Wire Size: 0.2–2.5 mm² (24–12 AWG).
Rated Current: Up to 15 A.
Rated Voltage: Up to 300 V AC.
Contact Material: Tin-Plated Copper Alloy.
Housing Material: PA66 Thermoplastic, UL94 V-0 Flame-Retardant.
Operating Temperature: -40°C to +105°C.
Colour: Green.
RoHS Compliant: Yes.
