TE Connectivity Buchanan Series 5mm Pitch Straight Pluggable Terminal Block, PCB Header, Panel Mount, 6 Way
SKU: CON6-0006-000
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The TE Connectivity Buchanan Series Pluggable Terminal Block PCB Header is a 6-way, straight PCB header intended for secure and dependable wire-to-board connections in industrial and commercial electronic applications.
This header, with a 5.0 mm pitch and panel-mount capabilities, pairs with appropriate Buchanan pluggable terminal block plugs to provide a strong and detachable connection for power and signal wiring.
The connector is made of high-quality tin-plated copper alloy contacts and a UL94 V-0 flame-retardant thermoplastic housing, resulting in good electrical performance, mechanical durability, and a long service life.
Its modular form facilitates installation, maintenance, and field wiring, making it excellent for control panels, power supply, automation equipment, and instrumentation.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: Pluggable Terminal Block PCB Header.
Manufacturer: TE Connectivity.
Series: Buchanan.
Number of Positions: 6 Way.
Pitch: 5.0 mm.
Configuration: Single Row.
Orientation: Straight (Vertical).
Mounting Type: PCB Through-Hole / Panel Mount.
Termination: Solder.
Connection Type: Pluggable.
Compatible Connector: TE Connectivity Buchanan Series Pluggable Terminal Block Plug.
Rated Current: Up to 15 A.
Rated Voltage: Up to 300 V AC.
Contact Material: Copper Alloy.
Contact Finish: Tin Plated.
Housing Material: Thermoplastic, UL94 V-0 Flame-Retardant.
Operating Temperature: -40°C to +105°C.
RoHS Compliant: Yes.
