RJ45 PCB Straight Socket 8-Pin unshielded
SKU: CON8-0004-000
Sold by Select Automation
Final price R 8.41
R 7.31 excl. VAT
Availability: In Stock (30 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The RJ45 PCB Straight Socket, 8-Pin is a high-quality 8P8C modular connector intended for dependable Ethernet and data connectivity applications.
Its straight (vertical) through-hole PCB attachment arrangement provides a secure interface for conventional RJ45 plugs while providing consistent signal transmission and mechanical stability.
This connector, made of robust, flame-retardant thermoplastic with precise gold-plated phosphor bronze contacts, provides good electrical performance and has a long service life.
It's perfect for networking equipment, industrial automation, embedded systems, telecommunications, and Internet of Things devices.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: RJ45 PCB Socket.
Connector Type: Female.
Configuration: 8P8C (8 Position, 8 Contact).
Number of Pins: 8.
Mounting Type: Through-Hole PCB.
Orientation: Straight (Vertical).
Shielding: Unshielded (UTP).
Contact Material: Phosphor Bronze.
Contact Finish: Gold over Nickel.
Housing Material: High-Temperature Thermoplastic, UL94 V-0.
Rated Current: 1.5 A.
Rated Voltage: 125 V AC.
Contact Resistance: ≤20 mΩ.
Insulation Resistance: ≥500 MΩ.
Operating Temperature: -40°C to +85°C.
RoHS Compliant: Yes.
