9-Way 5.08 mm Pitch Straight PCB Header
SKU: CON9-0010-000
Sold by Select Automation
Final price R 7.84
R 6.82 excl. VAT
Availability: In Stock (16 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 9-Way 5.08mm Pitch Straight PCB Header is a high-quality wire-to-board PCB connector that allows for secure and dependable pluggable terminal block connections.
This straight (vertical) through-hole PCB header, with its 9-position, single-row layout and 5.08 mm pitch, provides a strong connection for power and signal applications in industrial and commercial electronics.
The header, which is designed to work with compatible 5.08 mm pluggable terminal block plugs, enables simple installation, simplified maintenance, and secure field wiring.
Its tin-plated copper alloy contacts and UL94 V-0 flame-retardant PA66 housing provide good electrical performance, mechanical durability, and a long service life.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: PCB Terminal Block Header.
Number of Positions: 9 Way.
Configuration: 1 Row.
Pitch: 5.08 mm.
Orientation: Straight (Vertical).
Mounting Type: Through-Hole PCB.
Termination: Solder.
Connection Type: Wire-to-Board.
Compatible Connector: 5.08 mm Pitch Pluggable Terminal Block Plug.
Rated Current: Up to 15 A.
Rated Voltage: Up to 300 V AC.
Contact Material: Copper Alloy.
Contact Finish: Tin Plated.
Housing Material: PA66 Thermoplastic, UL94 V-0 Flame-Retardant.
Operating Temperature: -40°C to +105°C.
Colour: Green.
RoHS Compliant: Yes.
