Power supply units CX1100-0013
SKU: CX1100-0013
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Power supply: 24 V DC (-15 %/+20 %)
E-bus connection: –
K-bus connection: yes (adapter terminal)
IP-Link connection: yes
Current supply E-bus: –
Current supply K-bus: 2 A
Type of connection: spring-loaded technique (adapter terminal)
NOVRAM: 8 kbytes
Display: FSTN display 2 lines x 16 characters of text, illuminated
I/O-DPRAM: 4 kbytes
Diagnostics LED: 1 x PWR, 1 x I/O Run, 1 x I/O Err
Dimensions (W x H x D): 58 mm x 109 mm x 92 mm
Weight: approx. 325 g
Operating/storage temperature: 0…+55 °C/-25…+85 °C
Relative humidity: 95 %, no condensation
Vibration/shock resistance: conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission: conforms to EN 61000-6-2/EN 61000-6-4
Protection rating: IP20
Buy currently uses Select Automation shop pricing and checkout.
One of three power supply modules can be selected for CX1030 systems. The power supply of all other system components is ensured via the internal PC/104 bus; no separate supply lines are required. However, the CX1100 components offer further important characteristics that go beyond a pure power supply: an integrated NOVRAM enables the fail-safe storage of process data, an LC display with two lines of 16 characters each is used for displaying system and user messages. The CX1100-0013 power supply variant serves for the connection of local I/O signals, all Beckhoff Bus Terminals (KLxxxx) and Extension Box IExxxx type Beckhoff Fieldbus Box modules can be connected. The option to connect Bus Terminals or Fieldbus Box modules creates a control system with a very variable, expandable I/O level with large signal variety. The I/O data are stored in a DPRAM, which is accessible by the CPU via the system bus. The power supplies of the CX system can be exchanged in the field. The CX1100-001x power supply units are electronically identical to the CX1100-000x power supply units, but with an internal heat sink and additional ventilation apertures. Although they are intended for use with the CX1030, these power supply units can also be used with the CX1020 and CX1010 in order to enable alternative mounting directions.
