Din Rail Power Supply 24V DC 60W
SKU: DR-60-24
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The Mean Well DR-60-24 is an industrial DIN rail power supply with a 60W single output. It is intended to supply industrial applications with dependable and effective power.
Because of its small size, this power supply can be installed in confined areas. Because of its high efficiency and broad input voltage range, it provides steady and reliable performance.
To guarantee safe operation, the DR-60-24 is outfitted with several protection features, including as overload and overvoltage protection.
Specifications:
Output Voltage: 24V DC.
Output Current: 2.5A.
Output Power: 60W.
Input Voltage Range: 88 ~ 264VAC / 124 ~ 370VDC.
Efficiency: 84%.
Ripple & Noise: 150mVp-p.
Operating Temperature: -20°C to +60°C.
Dimensions: 78 x 93 x 56mm.
Protection: Overload, Overvoltage.
Compliance: UL60950-1, EN50178, EN55032 Class B, EN61000-3-2, -3, EN61000-4-2, 3, 4, 5, 6, 8, 11.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Output Voltage: 24V DC.
Output Current: 2.5A.
Output Power: 60W.
Input Voltage Range: 88 ~ 264VAC / 124 ~ 370VDC.
Efficiency: 84%.
Ripple & Noise: 150mVp-p.
Operating Temperature: -20°C to +60°C.
Dimensions: 78 x 93 x 56mm.
Protection: Overload, Overvoltage.
Compliance: UL60950-1, EN50178, EN55032 Class B, EN61000-3-2, -3, EN61000-4-2, 3, 4, 5, 6, 8, 11.
