Din Rail Power Supply 24V DC 75W
SKU: DR-75-24
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
A 75W industrial power supply with a single output that is intended for DIN rail mounting is the Mean Well DR-75-24.
It provides dependable performance with safeguards against overloads, short circuits, overvoltage, and overheating, making it perfect for a range of industrial applications.
This power supply is appropriate for challenging environments since it guarantees reliable and efficient power delivery.
Specifications:
Output Voltage: 24V DC.
Output Current: 3.2A.
Rated Power: 75 W.
Efficiency: 80%.
Input Voltage Range: 85-264VAC / 120-370VDC.
Frequency Range: 47-63Hz.
Operating Temperature: -10°C to +60°C.
Dimensions: 55.5mm (W) x 125.2mm (H) x 100mm (D).
Protections: Short circuit, overload, overvoltage, overtemperature.
Mounting Style: DIN rail.
Compliance: UL508, EAC TP TC 004, EN55032 Class B, EN61000-3-2, -3, EN61000-4-2,3,4,5,6,8,11.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Output Voltage: 24V DC.
Output Current: 3.2A.
Rated Power: 75 W.
Efficiency: 80%.
Input Voltage Range: 85-264VAC / 120-370VDC.
Frequency Range: 47-63Hz.
Operating Temperature: -10°C to +60°C.
Dimensions: 55.5mm (W) x 125.2mm (H) x 100mm (D).
Protections: Short circuit, overload, overvoltage, overtemperature.
Mounting Style: DIN rail.
Compliance: UL508, EAC TP TC 004, EN55032 Class B, EN61000-3-2, -3, EN61000-4-2,3,4,5,6,8,11.
