DTK TEMPERATURE CONTROLLER 14 VDC PULSE OUTPUT (96X96)
SKU: DTK9696V01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
"Low cost" temperature controller from the DTK series:
A new temperature controller with an excellent cost-performance ratio is the DTK series.
It enhances temperature control system performance and significantly reduces development time and expenses.
Operators can effortlessly keep an eye on the temperature in any setting or situation thanks to the compact design of this 60 mm long high-resolution LCD panel.
Buy currently uses Select Automation shop pricing and checkout.
Features:
High-speed 100 ms sample time, PID, ON/OFF, and manual control settings.
Nine customizable alarm modes and one alarm output.
A thermocouple is: K-J-T-E-N-R-S-B-L-U-TXK is the type.
Platinum RTD: JPt100, Pt100.
Control scheme: PID, manual control mode, ON/OFF.
Speed: 100 ms high-speed sampling time.
LCD screen: Value of Process (PV) Red: Set point (SV) colour green.
DTK Series:
SUPPLY VOLTAGE: 100 - 240 VAC.
FREQUENCY: 50/60 Hz.
INDEX PROTECTION IP: IP65.
PANEL SIZE (MM) - W X H: 96 x 96.
THERMOCOUPLE: Type (K-J-T-E-N-R-S-B-L-U-TXK) - Platinum RTD: Pt100, JPt100.
DESCRIPTION: Low-cost temperature controller.
LCD DISPLAY: Process Value (PV) Red colour - Set point (SV) Green colour.
OUPUT 1: 14 VDC pulse.
