3 PHASE VOLTAGE COMPARATOR 525VAC
SKU: DVW3525A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Comparison of the voltage window and phase failure.
Compact modular modules in the Electro D series of control and timing devices make it simple to integrate them into distribution boards or standard panels.
They align with ordinary tiny circuit breakers (MCBs) and attach straight onto DIN rail.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Monitors own supply.
Optional latch facility.
10A SPDT output relay.
4 Front face selectable delays.
Modular 35.5mm DIN rail mountable.
LED indication for power supply ON.
Over/under voltage monitoring / reversal.
High resolution analogue microprocessor.
LED indication for over and under voltage.
Front face adjustable over and under voltage levels.
Delays: No delay, startup delay 10 second,180 second recovery delay, reaction delay 10 second.
Three phase electronic timer with reversal:
CONTACT: 10A SPDT.
PHASE: Three phases.
DELAYS: No delay, startup delay 10 second,180 second recovery delay, reaction delay 10 second.
INPUT: Pin 1, 5 & 9 L1, L2 & L3.
RATED CURRENT: 10A.
RATED VOLTAGE: 250V.
MECHANICAL LIFE: 10x106 cycles.
PROTECTION INDEX IP: IP 20.
OPERATING TEMPERATURE: -10 to + 50°C.
STORAGE TEMPERATURE: -50 to + 85°C.
DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64.
