RSTI-EP Digital Input, 4 Points 110/230 VAC (65- 277 VAC), 2 Wire, Isolated
SKU: EP-1804
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The RSTi-EP remote I/O system is perfect for applications on the Industrial Internet.
It has high channel density, plug-and-play connectivity, improved diagnostics, and an expanded operational temperature range.
Support for PROFINET RT, PROFIBUS, Modbus TCP and EtherCAT.
Extended operating temperature range, enhanced diagnostics.
High-speed system bus reads up to 256 DI/DOs in 20 mS.
DIN rail mounted.
Plug-and-Play Installation.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: EP-1804
Input Count, Type & Speed: 4 Point, Positive Logic; 10mS w/Time Stamp
Supply Voltage and on/Off Voltage: 110VAC; Range 110~230VAC; On >85VAC; Off <65VAC
Current Consumption Isys & Iin: 8mA; N/A
Approvals & Standards Ordinary Locations: UL 508, CSA C22.2 No. 0-M91
Approvals & Standards Hazardous Locations: Class 1 Division 2, Gr. A, B, C, D, ISA 12.12.01: 2007 CSA C22.2 No. 213-M1987 (Reaffirmed 2008)
