RSTi-EP Digital Output, 16 Points, Positive Logic, 24VDC, 0.5A, RSTi-EP 1 Wire
SKU: EP-225F
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The RSTi-EP remote I/O system is perfect for applications on the Industrial Internet.
It has high channel density, plug-and-play connectivity, improved diagnostics, and an expanded operational temperature range.
Support for PROFINET RT, PROFIBUS, Modbus TCP and EtherCAT.
Extended operating temperature range, enhanced diagnostics.
High-speed system bus reads up to 256 DI/DOs in 20 mS.
DIN rail mounted.
Plug-and-Play Installation.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: EP-225F
Output Count, Type & Speed: 16 point positive logic; 1kHz resistive load switching
Output Rating: 0.5A 24VDC; 8A per module
Current Consumption Isys & Iin: 8mA; 25mA + loads, 20.4-28.8VDC
System Redundancy: PNSR
