RSTi-EP Analog Output, 4 Channels Voltage/Current 16 Bits 2, 3, or 4 Wire
SKU: EP-4164
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The RSTi-EP remote I/O system is perfect for applications on the Industrial Internet.
It has high channel density, plug-and-play connectivity, improved diagnostics, and an expanded operational temperature range.
Support for PROFINET RT, PROFIBUS, Modbus TCP and EtherCAT.
Extended operating temperature range, enhanced diagnostics.
High-speed system bus reads up to 256 DI/DOs in 20 mS.
DIN rail mounted.
Plug-and-Play Installation.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: EP-4164
Analog Output Count & Type: 4 points; Voltage/Current
Resolution & Speed: 16 bits; 1mS
Current Consumption Isys & Iin: 8mA 20.4-28.8VDC; 85mA 24VDC
System Redundancy: PNSR
Additional Capabilities: Voltage (0 – 5 V, ±5 V, 0 – 10 V, ±10 V, 1 – 5 V, 2 – 10 V); Current (0 – 20 mA, 4 – 20 mA)
