EP6002-0002 EtherCAT Box
SKU: EP6002-0002
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The EP6002-0002 serial interface module allows the connection of devices with an RS232 or RS422/RS485 interface. The module transmits the data in a fully transparent manner to the higher-level automation device. The data is transferred via the fieldbus using a simple handshake protocol.
Buy currently uses Select Automation shop pricing and checkout.
Protocol: EtherCAT
Bus interface: 2 x M8 socket, shielded, screw type
Data transfer channels: 2
Interfaces: individually selectable from RS232, RS485, RS422
Data transfer rate: 300…115,200 baud; 9600 baud (8 bit, no parity, 1 stop bit) is preset
Communication: TxD and RxD, full duplex
Bit distortion: < 3 %
Cable length: RS232: max. 15 m; RS422/RS485: approx. 1000 m
Data buffer: 864 bytes receive buffer, 128 bytes transmit buffer
Sensor supply: +5 V DC, 20 mA each, electrically isolated
Connection method: M12, screw type
Number of channels: 2 (1/1), TxD and RxD, full duplex
Nominal voltage: 24 V DC (-15 %/+20 %)
Current consumption from US: typ. 130 mA + sensor supply
Power supply connection: feed: 1 x M8 male socket, 4-pin; downstream connection: 1 x M8 female socket, 4-pin
Electrical isolation: 500 V
Weight: approx. 165 g
Special features: easy integration of serial end devices
Operating/storage temperature: -25…+60 °C/-40…+85 °C
Vibration/shock resistance: conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission: conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.: IP65/66/67 (conforms to EN 60529)/variable
Approvals/markings: CE, UL, ATEX
Ex marking: II 3 G Ex nA IIC T4 Gc
