EP7211-0035 EtherCAT Box, 1-channel motion interface, servomotor, 48 V DC, 4.5 A, OCT, suitable for STO applications

Bus interface: 2 x M8 socket, shielded, screw type Technology: compact drive technology Connection method: direct motor connection with OCT Number of inputs: 2 x end position, 1 x feedback, 1 x HWE Power supply connection: feed: 1 x 7/8" plug, 5-pin; downstream connection: 1 x 7/8" socket, 5-pin Load type: permanent magnet-excited three-phase synchronous motor Number of channels: 1 Number of outputs: 1 x servomotor, 1 x motor brake Supply voltage power: 8…48 V DC (external) Output current (rms): 4.5 A Peak current (rms): max. 9.0 A for 1 s Rotating field frequency: 0…599 Hz PWM clock frequency: 16 kHz Current controller frequency: 32 kHz Rated speed controller frequency: 16 kHz Output voltage motor brake: 24 V DC Output current motor brake: max. 0.5 A Current consumption from US: 120 mA Distributed clocks: yes Realization STO: hard-wired via safe output Special features: compact and system-integrated, absolute feedback, One Cable Technology (OCT), plug and play, STO (Safe Torque Off), preset drive profile CiA DS402 Safe stop functions: Safe Torque Off (STO) Electrical isolation: 500 V Weight: approx. 500 g Operating/storage temperature: -25…+60 °C/-40…+85 °C EMC immunity/emission: conforms to EN 61000-6-2/EN 61000-6-4 Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27 Protect. rating/installation pos. IP65/66/67 (conforms to EN 60529)/variable Approvals/markings: CE, UL, TÜV SÜD
