EPP6002-0002 EtherCAT P Box
SKU: EPP6002-0002
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 1-channel version has an increased end device power supply of up to 1 A, the connector assignment depends on the selected interface. The two integrated digital inputs/outputs allow the connection of additional sensors/actuators in order, for example, to trigger the reading process of the barcode reader or, depending on the result, to initiate an action.
Buy currently uses Select Automation shop pricing and checkout.
Protocol: EtherCAT
Bus interface: 2 x M8 socket, shielded, screw type, P-coded
Data transfer channels: 2
Interfaces: individually selectable from RS232, RS485, RS422
Data transfer rates: 300…115,200 baud; 9600 baud (8 bit, no parity, 1 stop bit) is preset
Bit distortion: < 3 %
Cable length: RS232: max. 15 m; RS422/RS485: approx. 1000 m
Data buffer: 864 bytes receive buffer, 128 bytes transmit buffer
Sensor supply: +5 V DC, 20 mA each
Connection method: M12, screw type
Number of channels: 2 (1/1), TxD and RxD, full duplex
Nominal voltage: 24 V DC (-15 %/+20 %)
Current consumption from US: typ. 100 mA
Electrical isolation: 500 V
Weight: approx. 165 g
Special features: easy integration of serial end devices
Operating/storage temperature: -25…+60 °C/-40…+85 °C
Vibration/shock resistance: conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission: conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.: IP65/66/67 (conforms to EN 60529)/variable
Approvals/markings: CE, UL
