EPP7342-0002 EtherCAT P Box
SKU: EPP7342-0002
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The EPP7342 EtherCAT P Box enables direct operation of two DC motors. The speed or position is specified by the automation device via a 16-bit value. By connection of an incremental encoder (24 V DC, single-ended), a simple servo axis can be realized. The output stage is protected against overload and short-circuit.
Buy currently uses Select Automation shop pricing and checkout.
Protocol: EtherCAT
Bus interface: 2 x M8 socket, shielded, screw type, P-coded
Number of outputs:2
Connection method: M12, screw type
Rated load voltage: 8…48 V DC
Load type: DC brush motor, inductive
Output current: per channel max. 3.5 A (short-circuit proof, common thermal overload warning for both output stages)
Distributed clocks: yes
PWM clock frequency: 32 kHz with 180° phase shift each
Duty factor: 0…100 % (voltage-controlled)
Resolution: max. 10 bit current, 16 bit speed
Electrical isolation: 500 V
Configuration: adaptation and optimisation of the respective motor via the controller
Current consumption sensor supply: 20 mA (see documentation)
Current consumption from US: typ. 100 mA
Special features: travel distance control, encoder input
Operating/storage temperature: -25…+60 °C/-40…+85 °C
Weight: approx. 165 g
Vibration/shock resistance: conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission: conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.: IP65/66/67 (conforms to EN 60529)/variable
Approvals/markings: CE, (UL in preparation)
